Saturday, April 20, 2013

The abridged death of stars

Just A Short Note Series #3


START:
MAIN SEQUENCE STAR
  • Hydrogen fusion (Simplified: H or D to He)
  • Lifespan: millions to billions of years
EVENT:
+ Hydrogen fuel is depleted and fails to support further nuclear fusion
+ Stellar temperature drops and fails to keep star stable
+ Stellar core contracts under its own gravity
+ Stellar core temperature and pressure increase
+ Helium fusion takes over (Simplified: He to C)
+ Outer stellar layer pushed away from core by this novel energy release, cools down, becomes red in color

RESULT:
RED GIANT
  • Helium fusion
  • Lifespan: millions of years
EVENT:
+ Helium fuel is eventually depleted and fails to support further nuclear fusion

RESULT:
[1] Stellar mass > 5 times solar mass: HIGH MASS STELLAR DEATH
[2] Stellar mass <= 5 times solar mass: LOW MASS STELLAR DEATH

EVENT:
[1] LOW MASS STELLAR DEATH
+ Stellar core contracts once more
+ But only sufficient to ignite fusion of remaining Helium in the shell around stellar core
+ Resultant stellar instability with pulsating surface activity

RESULT:
VARIABLE STAR
  • Helium fusion
  • Constantly changing in brightness and size
  • [1A] Outer stellar layers drift away into space in pulses: "PLANETARY" NEBULA
  • [1B] Inner stellar core eventually exposed: WHITE DWARF
EVENT:
[1BI] For a solitary white dwarf, nuclear fusion ceases
[1BII] In a binary star system, stellar material funnels from the red giant to the white dwarf; this newly accreted material provides energy to reignite a "runaway" nuclear fusion

RESULT:
[1BI] N/A
[1BII] SUPERNOVA (TYPE IA)*
  • Carbon fusion (Simplified: C to O, N, etc)
  • Lifespan: weeks to months
Figure 1

EVENT:
[2] HIGH MASS STELLAR DEATH
+ Stellar core contracts once more
+ But has sufficient pressure to ignite Carbon fusion (Simplified: C to O, N, Ne; which fuse to Na, Mg, Si, S; which fuse to Fe, Ni, Co etc)
+ Iron, which is very stable and resists further fusion, accumulates in stellar core
+ When Iron accumulation reaches a critical mass (1.5 times solar mass) after millions of years, electrons are forced out of orbit by gravity
+ These electrons then merge with Iron nuclei, instantaneously reducing stellar volume
+ Extreme potential energy is released in shockwaves colliding with outer stellar materials

RESULT:
SUPERNOVA (TYPE IB, IC, II)*
  • Fusion of heavier elements producing all known natural elements in the universe
  • Lifespan: weeks to months
  • [2A] SUPERNOVA REMNANT
    [2B] STELLAR REMNANT
Figure 2

GAMMA RAY BURST
  • GRB is the brightest electromagnetic emission event observed in the universe
  • It is followed by less energetic emission of longer wavelengths: AFTERGLOW
  • Lifespan: milliseconds to minutes
Figure 3

[2A] SUPERNOVA REMNANT
  • Compact gaseous nebula
  • Glows brilliantly due to radioactive decay of fusion products
  • Expelled at great velocity, expands into space and eventually fades
  • May collide with molecular clouds during expansion, producing "COMETARY" KNOT
[2B] STELLAR REMNANT
  • As noted above, stellar remnant mass is always > 1.5 times solar mass
  • The Tolman-Oppenheimer-Volkoff Limit is around 3.5-4 times solar mass
EVENT:
[2BI] Stellar remnant < TOV Limit: neutron-degenerate matter remains stable
[2BII] Stellar remnant near TOV Limit: individual neutrons break down due to gravity
[2BIII] Stellar remnant > TOV Limit: neutron-degenerate pressure is exceeded: implosion

RESULT:
[2BI] NEUTRON STAR
  • Very compact star 15-20km in diameter
  • PULSAR: a strongly magnetic, spinning neutron start that emits rhythmic bursts of radio waves
  • MAGNETAR: a neutron star with an even stronger magnetic field; may emit GRB
Figure 4

[2BII] QUARK STAR (STRANGE STAR)
  • A hypothetical ultra-dense star heavier but smaller than a neutron star
  • Neutrons break down under immense gravity into constituent up- and down-quarks
  • Some may change to strange-quarks, forming a phase of strange-matter
Figure 5

[2BIII] BLACK HOLE
  • A region of deformed spacetime within which gravity prevents anything, including electromagnetic radiation (e.g. light) from escaping beyond a "point of no return" called the Event Horizon, thereby blocked from the external observation
  • It has only three independent physical properties:
  • Mass, Charge, Angular momentum (rotational or non-rotational)
  • Rotating black holes are surrounded by a region of spacetime in which it is impossible to stand still, called the Ergosphere, but still possible to escape
  • Matter falls into the accretion disc of a Black Hole so that it grows continuously
  • This process is heated by friction and emits radiation at Event Horizon
  • At the center of a Black Hole is a region where spacetime curvature becomes infinite: GRAVITATIONAL SINGULARITY

Figure 6

* N.B. Supernovae are classified according to their light curves and the absorption lines of different elements in their spectra.

Figure 1: Supernova remnant RCW86 is the result of a supernova explosion in AD 185. Expending shockwave at x-ray energy heats interstellar gas (blue and green), while cooler infrared energy radiates from interstellar dust (yellow and red). Abundance of iron but lack of a neutron star suggest that a white dwarf had been destroyed in a binary star system.

Figure 2: Crab nebula M1 is the result of a supernova explosion in AD 1054. In this event the stellar remnant is the Crab pulsar.

Figure 3: Wolf-Rayet star WR124 and its surrounding nebula. These extremely hot and massive stars have shed most of their hydrogen. They are candidates for future GRB.

Figure 4: Supernova remnant Cassiopeia A with a rapidly cooling neutron star having a core of frictionless neutron superfluid.

Figure 5: Neutron star RX J1856.5-3754 in the constellation Corona Australis had been previously suggested to be a quark star. Other candidates remain.

Figure 6: Binary Black Hole in 3C75 (in galaxy cluster Abell 400) co-orbiting at the core of two merging galaxies and blasting out jets of intense radio wave emission. Besides supernovae, this is another mechanism from which Black Holes can form.

Friday, September 11, 2009

The Open Dinosaur Project

A chance for everyone of us to participate in research!
A chance to discover and learn about dinosaurs!
A chance to analyse data on Ornithischians!

ALL FOR ONE AND ONE FOR ALL

Member, The Open Dinosaur Project

Monday, June 01, 2009

Quiz-mania!!! [Answers and explanations]

Please refer to my facebook notes for the questions.

(Q I)
(A) False. Animal A is an obligate biped.
(B) False. All predators scavenge to some degree.
(C) True. All vertebrates are cordates.
(D) True. {Mammal + Dinosaur {Bird}}
(E) False. {Lissamphibian + {Mammal + Dinosaur}}

(Q II)
FMNH PR 2081 is the most complete specimen.
Relevant phenomena include: allometry (body proportion influenced by size i.e. weight bearing), ontogeny (body proportion influenced by growth and maturation), sexual dimorphism (although this is controversial for tyrannosaurs), pathology, post-mortem and diagenetic distortion of skeletal components, developmental anomaly (more relevant in teeth aberration) etc.

(Q III)
No specimen represents baby or juvenile.
This is suggested by the observation that even the smallest specimen (BHI 3033) displays nasal rugosity and post-orbital bar (giving the "keyhole" orbit) - features of maturity.

(Q IV)
- Increased robustness of bony components of the skull
- Weight saving bony reduction in non force-transmitting areas (see Molnar, 1998)
- Curved maxillary teeth line producing an effective torque
- Mediolaterally expanded teeth effectively bear the impact of bite
- Thickened dentary "step" harboring strong abductor mandibular complex muscles

(Q V)
- Compact and robust cervical vertebrae anchoring strong neck and epaxial muscles
- Foreshortened pre-sacral torso to pull back center of mass towards pelvis
- Reduced forelimb (possibly to save weight)

(Q VI)
BHI - Black Hills Institute
CM - Carnegie Museum of Natural History
AMNH - American Museum of Natural History
MOR - Museum of the Rockies
FMNH - Field Museum of Natural History (Chicago)

Reference
Molnar R (1998). Gaia 15:167 [This volume is actually published in 2000]
